Inverter heating with r-290
| application name | Heat pump |
| Compressor Type | Scroll |
| condition type | Heat Pump |
| Displacement (CC) | 28.3 - 52.2 |
| motor type | - BLDCM |
| Nominal output (Watt) | 1470 - 2180 |
| rate voltage | 80 - 240 |
| phase | 3 |
| motor protector | External |
| Oil type | PZ46M |
| piping vibration | Limit Maximum 0.8 mm. |
| MODEL | CAPACITY | Hz | INPUT | COP. | EER. | PHASE | RUN CAP. | WEIGHT | OIL Q'TY | Oil Solution | Sound Solution | ADD |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| W | W | (W/W) | (Btu/hr*w) | (MF/VAC) | (kgs.) | (cc.) | ||||||
| DPB28FB3MT | 4,390 (Heat Pump) | 180 | 1,430 | 3.06 | 11.92 | 3 | - | 21.9 | 900 | - | - | |
| DPB36FF3MT | 5,600 (Heat Pump) | 180 | 1,700 | 3.29 | 12.19 | 3 | - | 21.9 | 900 | - | - | |
| DPB52FB1MT | 8,400 (Heat Pump) | 120 | 2,450 | 3.42 | 12.28 | 3 | - | 22.72 | 900 | - | - |
